CS4360
8 DS517F2
3. CHARACTERISTICS AND SPECIFICATIONS
Typical performance characteristics are derived from measurements taken at T
A
= 25
°C. Min/Max performance
characteristics and specifications are guaranteed over the operating temperature and voltages.
SPECIFIED OPERATING CONDITIONS
GND = 0 V; all voltages with respect to GND.
ABSOLUTE MAXIMUM RATINGS
GND = 0 V; all voltages with respect to GND. Operation beyond these limits may result in permanent damage to
the device. Normal operation is not guaranteed at these extremes.
Notes: 1. Nominal VD supply must be less than or equal to the nominal VA supply.
2. Any pin except supplies.
Parameters Symbol Min Typ Max Units
DC Power Supply
Analog 3.3 V Nominal
(Note 1) 5.0 V Nominal
VA 3.0
4.5 3.3
5
3.6
5.5 V
V
Digital 2.5 V Nominal
(Note 1) 3.3 V Nominal
5.0 V Nominal
VD 2.25
3.0
4.5
2.5
3.3
5
2.75
3.6
5.5
V
V
V
Serial Audio Interface 1.8 V Nominal
2.5 V Nominal
3.3 V Nominal
5.0 V Nominal VLS 1.7
2.25
3.0
4.5
1.8
2.5
3.3
5
1.9
2.75
3.6
5.5
V
V
V
V
Control Port Interface 1.8 V Nominal
2.5 V Nominal
3.3 V Nominal
5.0 V Nominal VLC 1.7
2.25
3.0
4.5
1.8
2.5
3.3
5
1.9
2.75
3.6
5.5
V
V
V
V
Parameters Symbol Min Max Units
DC Power Supply Analog
Digital
Serial Audio Interface
Control Port Interface
VA
VD
VLS
VLC
-0.3
-0.3
-0.3
-0.3 6.0
6.0
6.0
6.0 V
V
V
V
Input Current (Note 2) I
in
- ±10 mA
Digital Input Voltage Serial Audio Interface
Control Port Interface
V
IND_S
V
IND_C
-0.3
-0.3 VLS+0.4
VLC+0.4 V
V
Ambient Operating Temperature (power applied) T
A
-55 125 °C
Storage Temperature T
stg
-65 150 °C
