5. REGISTER QUICK REFERENCE
Addr Function 7 6 5 4 3 2 1 0
1h Mode Control 1 AMUTE DIF2 DIF1 DIF0 DEM1 DEM0 FM1 FM0
default 1 0 0 0 0 0 0 0
2h Invert Signal Reserved Reserved INV_B3 INV_A3 INV_B2 INV_A2 INV_B1 INV_A1
default 0 0 0 0 0 0 0 0
3h Mixing Control P1 Reserved Reserved Reserved Reserved P1ATAPI3 P1ATAPI2 P1ATAPI1 P1ATAPI0
default 0 0 0 0 1 0 0 1
4h Mixing Control P2 Reserved Reserved Reserved Reserved P2ATAPI3 P2ATAPI2 P2ATAPI1 P2ATAPI0
default 0 0 0 0 1 0 0 1
5h Mixing Control P3 Reserved Reserved Reserved Reserved P3ATAPI3 P3ATAPI2 P3ATAPI1 P3ATAPI0
default 0 0 0 0 1 0 0 1
6h Volume Control A1 A1_MUTE A1_VOL6 A1_VOL5 A1_VOL4 A1_VOL3 A1_VOL2 A1_VOL1 A1_VOL0
default 0 0 0 0 0 0 0 0
7h Volume Control B1 B1_MUTE B1_VOL6 B1_VOL5 B1_VOL4 B1_VOL3 B1_VOL2 B1_VOL1 B1_VOL0
default 0 0 0 0 0 0 0 0
8h Volume Control A2 A2_MUTE A2_VOL6 A2_VOL5 A2_VOL4 A2_VOL3 A2_VOL2 A2_VOL1 A2_VOL0
default 0 0 0 0 0 0 0 0
9h Volume Control B2 B2_MUTE B2_VOL6 B2_VOL5 B2_VOL4 B2_VOL3 B2_VOL2 B2_VOL1 B2_VOL0
default 0 0 0 0 0 0 0 0
0Ah Volume Control A3 A3_MUTE A3_VOL6 A3_VOL5 A3_VOL4 A3_VOL3 A3_VOL2 A3_VOL1 A3_VOL0
default 0 0 0 0 0 0 0 0
0Bh Volume Control B3 B3_MUTE B3_VOL6 B3_VOL5 B3_VOL4 B3_VOL3 B3_VOL2 B3_VOL1 B3_VOL0
default 0 0 0 0 0 0 0 0
0Ch Mode Control 2 SZC1 SZC0 CPEN PDN POPG FREEZE MCLKDIV SNGLVOL
default 1 0 0 1 1 0 0 0
0Dh Revision Indicator Reserved Reserved Reserved Reserved REV3 REV2 REV1 REV0
default 0 0 0 0 X X X X
