DC ELECTRICAL CHARACTERISTICS
GND = 0 V; all voltages with respect to GND.
Notes: 13. Normal operation is defined as RST = HI with a 997 Hz, 0 dBFS input sampled at the highest F
s
for each
speed mode, and open outputs, unless otherwise specified.
14. I
LC
measured with no external loading on pin 12 (SDA).
15. Power Down Mode is defined as RST = LO with all clocks and data lines held static.
16. Valid with the recommended capacitor values on FILT+ and VQ as shown in Figure 1. Increasing the
capacitance will also increase the PSRR.
DIGITAL INPUT CHARACTERISTICS
GND = 0 V; all voltages with respect to GND.
Parameters Symbol Min Typ Max Units
Normal Operation (Note 13)
Power Supply Current VA = 5.0 V
VD = 5.0 V
VA = 3.3 V
VD = 3.3 V
VLS = 5.0 V
VLC = 5.0 V
VLS = 3.3 V
VLC = 3.3 V
(Note 14)
I
A
I
D
I
A
I
D
I
LS
I
LC
I
LS
I
LC
-
-
-
-
-
-
-
-
22
25
21
14
6
2
2
1
-
-
-
-
-
-
-
-
mA
mA
mA
mA
µA
µA
µA
µA
Power Dissipation All Supplies = 5.0 V
All Supplies = 3.3 V
-
- 235
116 265
128 mW
mW
Power-down Mode (Note 15)
Power Supply Current All Supplies = 5.0 V
All Supplies = 3.3 V
-
- 16
12 -
-
µA
µA
Power Dissipation All Supplies = 5.0 V
All Supplies = 3.3 V
-
- 80
40 -
-
µW
µW
All Modes of Operation
Power Supply Rejection Ratio (Note 16) 1 kHz
60 Hz
PSRR -
- 60
40 -
- dB
dB
V
Q
Nominal Voltage
Output Impedance
Maximum allowable DC current source/sink
-
-
- 0.5•VA
250
0.01
-
-
- V
k
Ω
mA
Filt+ Nominal Voltage
Output Impedance
Maximum allowable DC current source/sink
-
-
- VA
250
0.01
-
-
- V
k
Ω
mA
MUTEC Low-level Output Voltage - 0 - V
MUTEC High-level Output Voltage - VA - V
Maximum MUTEC Drive Current - 3 - mA
Parameters Symbol Min Typ Max Units
Input Leakage Current I
in
- - ±10 µA
Input Capacitance - 8 - pF
