DS702F1 7
CS3308
2. CHARACTERISTICS AND SPECIFICATIONS
All Min/Max characteristics and specifications are guaranteed over the Specified Operating Conditions. Typical
performance characteristics and specifications are derived from measurements taken at nominal supply voltages
and T
A
= 25 °C.
SPECIFIED OPERATING CONDITIONS
(DGND = 0 V; All voltages with respect to ground.)
ABSOLUTE MAXIMUM RATINGS
(DGND = 0 V; All voltages with respect to ground. (Note 1)
Notes:
1. Operation beyond these limits may result in permanent damage to the device.
Normal operation is not guaranteed at these extremes.
2. Any pin except supplies. Transient currents of up to ±100 mA on the analog input pins will not cause
SCR latch-up.
Parameters Symbol Min Nom Max Units
DC Power Supplies: Positive Analog
Negative Analog
Digital
VA+
VA-
VD
4.75
-5.25
3.1
5
-5
3.3
5.25
-4.75
3.5
V
V
V
Ambient Operating Temperature (Power Applied) T
A
-10 - +70 °C
Parameter Symbol Min Max Units
DC Power Supplies: Positive Analog
Negative Analog
Digital
VA+
VA-
VD
-0.3
-7.0
-0.3 7.0
0.3
3.63
V
V
V
Input Current (Note 2) I
in
-
±10
mA
Analog Input Voltage V
INA
(VA-) - 0.3 (VA+) + 0.3 V
Digital Input Voltage V
IND
VD - 0.3 VD + 0.3 V
Ambient Operating Temperature (Power Applied) T
A
-55 +125 °C
Storage Temperature T
stg
-65 +150 °C
