DS702F1 29
CS3308
6. CS3308 REGISTER QUICK REFERENCE
This table shows the register names and their associated default values.
Addr Function 7 6 5 4 3 2 1 0
01h Ch. 1 Volume Vol7 Vol6 Vol5 Vol4 Vol3 Vol2 Vol1 Vol0
page 31 1 1 0 1 0 0 1 0
02h Ch. 2 Volume Vol7 Vol6 Vol5 Vol4 Vol3 Vol2 Vol1 Vol0
page 31 1 1 0 1 0 0 1 0
03h Ch. 3 Volume Vol7 Vol6 Vol5 Vol4 Vol3 Vol2 Vol1 Vol0
page 31 1 1 0 1 0 0 1 0
04h Ch. 4 Volume Vol7 Vol6 Vol5 Vol4 Vol3 Vol2 Vol1 Vol0
page 31 1 1 0 1 0 0 1 0
05h Ch. 5 Volume Vol7 Vol6 Vol5 Vol4 Vol3 Vol2 Vol1 Vol0
page 31 1 1 0 1 0 0 1 0
06h Ch. 6 Volume Vol7 Vol6 Vol5 Vol4 Vol3 Vol2 Vol1 Vol0
page 31 1 1 0 1 0 0 1 0
07h Ch. 7 Volume Vol7 Vol6 Vol5 Vol4 Vol3 Vol2 Vol1 Vol0
page 31 1 1 0 1 0 0 1 0
08h Ch. 8 Volume Vol7 Vol6 Vol5 Vol4 Vol3 Vol2 Vol1 Vol0
page 31 1 1 0 1 0 0 1 0
09h ¼ dB Control Quarter8 Quarter7 Quarter6 Quarter5 Quarter4 Quarter3 Quarter2 Quarter1
page 32 0 0 0 0 0 0 0 0
0Ah Mute Control MuteCh8 MuteCh7 MuteCh6 MuteCh5 MuteCh4 MuteCh3 MuteCh2 MuteCh1
page 33 0 0 0 0 0 0 0 0
0Bh Device Config 1 Reserved Reserved EnMuteIn MutePolarity Ch8=7 Ch6=5 Ch4=3 Ch2=1
page 33 0 0 1 0 0 0 0 0
0Ch Device Config 2 Reserved Reserved Reserved TimeOut2 TimeOut1 TimeOut0 ZCMode1 ZCMode0
page 34 0 0 0 0 1 1 0 1
0Dh Channel Power PDN8 PDN7 PDN6 PDN5 PDN4 PDN3 PDN2 PDN1
page 35 0 0 0 0 0 0 0 0
0Eh Master Power Reserved Reserved Reserved Reserved Reserved Reserved Reserved PDN_ALL
page 35 0 0 0 0 0 0 0 1
0Fh Freeze Control Reserved Reserved Reserved Reserved Reserved Reserved Reserved Freeze
page 36 0 0 0 0 0 0 0 0
