ANALOG CHARACTERISTIC (Cont.)
Notes: 13. Ratio of common mode input amplitude vs. differential mode output amplitude for a perfectly matched
common mode input signal. Characterized with a 50 Hz, 500 mV
peak
common mode sine wave applied
to the analog inputs.
14. Output impedance characteristics are approximate and can vary up to +/- 30% depending on process
parameters.
Parameter
Symbol
CS3302A
Unit
Min
Typ
Max
Analog Input Characteristics
Input Signal Frequencies
BW
DC
-
2000
Hz
Input Voltage Range (Signal + Vcm)
x1
x2 - x64
V
IN
(VA-)+0.7
(VA-)+0.7
-
-
(VA+)-1.25
(VA+)-1.75
V
Full Scale Input, Differential
x1
x2
x4
x8
x16
x32
x64
V
INFS
-
-
-
-
-
-
-
-
-
-
-
-
-
-
5
2.5
1.25
625
312.5
156.25
78.125
V
p-p
V
p-p
V
p-p
mV
p-p
mV
p-p
mV
p-p
mV
p-p
Input Impedance, Differential
Z
INDIFF
-
1, 20
-
T
Ω, pF
Input Impedance, Common Mode
Z
INCM
-
0.5, 40
-
T
Ω, pF
Input Bias Current
I
IN
-
1
40
pA
Crosstalk, Multiplexed Inputs
(
)
XT
-
-130
-
dB
Common to Differential Mode Rejection
(
)
CDMR
90
100
-
dB
Analog Output Characteristics
Full Scale Output, Differential
V
OUT
-
-
5
V
pp
Output Voltage Range (Signal + Vcm)
V
RNG
(VA-)+0.5
-
(VA+)-0.5
V
Output Impedance
(
)
Z
OUT
-
40
-
Ω
Output Impedance Drift
(
)
Z
TC
-
0.38
-
Ω/°C
Output Current
I
OUT
-
-
+25
mA
Load Capacitance
C
L
-
-
100
nF
Guard Output Characteristics
Guard Output Voltage
V
GUARD
-
V
cm
-
V
Guard Output Impedance
ZG
OUT
-
500
-
Ω
Guard Output Current
IG
OUT
-
40
-
µA
Guard Load Capacitance
CG
L
-
-
100
pF
