CS3302A
CS3302A
DS765PP1
6 DS765PP1
ANALOG CHARACTERISTICS (CONT.)
Notes: 6. Common mode signals pass unchanged through the differential amplifier architecture and are rejected
by the CS5371A / 72A / 73A modulator CMRR.
7. Absolute gain accuracy tests the matching of x1 gain across multiple CS3302A devices.
8. Relative gain accuracy tests the tracking of x1,x2, x4,x16,x32,x64 gain relative to x1 gain on a single
CS3302A device.
9. Specification is for the parameter over the specified temperature range and is for the CS3302A device
only. It does not include the effects of external components.
10. Offset voltage is tested with the amplifier inputs connected to the internal 800
Ω termination.
11. The absolute offset after calibration specification applies to the effective offset voltage of the CS3302A
output when used with the CS5371A / 72A / 73A modulator and the CS5376A / 78 digital filter, and is
measured from the digitally calibrated output codes of the CS5376A / 78.
12. The CS3302A offset calibration is performed digitally with the CS5371A / 72A / 73A modulator and
CS5376A / 78 digital filter and includes the full scale signal range. Calibration offsets of greater than +
5% of full scale will begin to subtract from system dynamic range.
Parameter Symbol
CS3302A
Unit Min Typ Max
Gain
Gain, Differential GAIN x1 - x64
Gain, Common Mode ( Note 6) GAIN
CM
- x1 -
Gain Accuracy, Absolute ( Note 7 ) GAIN
ABS
- ±1 ±2 %
Gain Accuracy, Relative ( Note 8 ) x2
x4
x8
x16
x32
x64 LIN
-0.4
-
-
-
-
-
-0.2
-0.2
-0.2
-0.2
-0.2
-0.2 0
-
-
-
-
-
%
Gain Drift ( Note 4, 9) GAIN
TC
- 5 - ppm / ºC
Offset
Offset Voltage, Input Referred ( Note 10 ) OFST - +250 +750 µV
Offset After Calibration, Absolute ( Note 11 ) OFST
CAL
- +1 - µV
Offset Calibration Range ( Note 12 ) OFST
RNG
- 100 - % F.S.
Offset Voltage Drift ( Note 4, 9 ) OFST
TC
- 1 - µV / ºC
