ANALOG CHARACTERISTICS (CONT.)
Notes: 13. Ratio of input common mode amplitude vs. output differential mode amplitude for a perfectly matched
common mode input signal. Characterized with a 50 Hz, 500 mV
peak
common mode sine wave applied
to the analog inputs.
14. Output impedance characteristics are approximate and can vary up to ±30% depending on process
parameters.
Parameter
Symbol
CS3301A
Unit
Min
Typ
Max
Analog Input Characteristics
Input Signal Frequencies
BW
DC
-
2000
Hz
Input Voltage Range (Vcm ± Signal)
x1
x2 to x64
V
IN
(VA-)+0.7
(VA-)+0.7
-
-
(VA+)-1.25
(VA+)-1.75
V
Full Scale Input, Differential
x1
x2
x4
x8
x16
x32
x64
V
INFS
-
-
-
-
-
-
-
-
-
-
-
-
-
-
5
2.5
1.25
625
312.5
156.25
78.125
V
p-p
V
p-p
V
p-p
mV
p-p
mV
p-p
mV
p-p
mV
p-p
Input Impedance, Differential
Z
INDIFF
-
1, 50
-
G
Ω, pF
Input Impedance, Common Mode
Z
INCM
-
1
-
M
Ω
Input Bias Current
I
IN
-
1
2
nA
Crosstalk, Multiplexed Inputs
(
XT
-
-130
-
dB
Common to Differential Mode Rejection
CDMR
95
120
-
dB
Analog Output Characteristics
Full Scale Output, Differential
V
OUT
-
-
5
V
p-p
Output Voltage Range (Vcm ± Signal)
V
RNG
(VA-)+0.5
-
(VA+)-0.5
V
Output Impedance
Z
OUT
-
40
-
Ω
Output Impedance Drift
Z
TC
-
0.24
-
Ω/°C
Output Current
I
OUT
-
-
±25
mA
Load Capacitance
C
L
-
-
1
nF
