Stability character [space] if stable
[?] if not stable
[^] if an indication over the range
[v] if fan indication below the range
sign [space] for positive values or
[-] for negative values
mass 9 characters justified to the right
unit 3 characters justified to the left
command 3 characters justified to the left
The frame format sent by the indicator in case of setting
to Cntb:
1 2 3 4 5 6 7-15 16 17 18 19 20 21
S U I stability space sign mass space unit CR LF
20.7. Configuring printouts
General information
If some information included are redundant or not sufficient and there
is a necessity of changes one can design their own protocol format in
EDYTOR WAG computer program. This piece of software is accessible
in: http://www.radwag.com
21. ERROR COMMANDS
Err2 - Value beyond the zero range
Err3 - Value beyond the tare range
Err4 - Calibration mass or start mass beyond the acceptable
range (
±1% for weight, ±10 for start mass)
Err5 - Mass of a single piece lower than the scale division
Err8 - Exceeded the time for tarring, zeroing, start mass
adjustment or span adjustment
