14. RS 232 PARAMETERS
External devices connected to RS 232C have to be supplied from the
same mains and common electric shock protection. It prevents from
appearing a potential difference between zero leads of the two devices.
This notice does not apply to the devices that do not use zero leads.
Transmission parameters:
• Baud rate - 2400 ÷ 38400 bit / s
• Data bits - 7,8
• Stop bits - 1,2
• Parity control - no, even, odd
There are four ways of sending data via RS232 interface:
• Manually – after pressing
,
• Automatically – after stabilizing the indication over -LO- threshold
• Continuously – after it is activated in parameter or by a command
sent via RS232
• On external request - see - „List of scale - computer commands”.
The indication can be sent as:
• stable – the indication is sent after the scale stabilizes.
• any – the indication is sent immediately after pressing the
key,
this state is assign with in the printout.
14.1. Printout type
This parameter is to select the type of printout.
Procedure:
• Enter the submenu and then:
- 24 -
