Display Configurations 35
3 Click Extend my Windows desktop onto this monitor .
4 Set the Screen Resolution and Color Quality as appropriate for the
second monitor. Click Apply or OK to apply these new values.
Refer to your Windows online help and documentation for further information
on using the
Settings tab.
Display Configurations
Your All-in-Wonder® X800 PCI Express® graphics card provides dual
display functionality and TV Out. The following table lists the different ways
you can connect displays to your card.
L
When you use multiple monitors with your card, one monitor will
always be Primary. Any additional monitors will be designated as
Secondary.
Display
Configuration Connector(s)
Used Comments
Single CRT
display VGA connector OR
DVI-I connector
with DVI-I-to-VGA
adapter CRT- cathode ray tube analog
display.
Single DFP
display DVI-I connector DFP - digital flat panel display.
Single TV S-Video Out The S-Video Out can also support a
composite connection via the
S-Video-to-Composite adapter.
Single HDTV
display HDTV Output
Adapter HDTV - High Definition Television
CRT display +
TV VGA connector +
S-Video Out UNSUPPORTED CONFIGURATION
if the CRT display is attached to the
DVI-I connector via the DVI-I-to-VGA
adapter.
CRT display +
HDTV VGA connector +
HDTV (YPrPb)
output cable
