12 Input and Output Adapters
Compatibility with Earlier All-in-Wonder® Products
If you have input and output devices connected to an earlier All-in-
Wonder® product, the input/output adapter included with your All-in-
Wonder® X800 PCI Express® card lets you easily reattach those devices.
1 Input / Output Adapter.
2 All-in-Wonder® X800 PCI Express® card.
3 ATI HD Output Adapter.
4 Cables with RCA plug at each end, available separately from a
consumer electronics dealer.
5 Typical HDTV video inputs.
Note: Input and output cable lengths should not exceed 50 feet
(15m).
Y = Green
Pb = Blue
Pr = Red
6 Cable with mini-stereo plug at each end, available separately from a
consumer electronics dealer, for connecting PC speakers (optional).
7 LINE IN to sound card
8 Dolby® Digital AC-3 Amplifier.
9 Cable with RCA plug at each end, available separately from a
consumer electronics dealer.
