AI_TRANSDUCER Block (PA Slot 3) Parameter List
.8 .6 .Diagnostic .parameters
Parameter
Rel.
Index
PA
Description Type Store Size
byte
RO /
R/W Min. Max. Default
INPUT_FAULT_GEN 4
Input .malfunction: .Diagnosis .object .for .errors .that .con-
cern .all .values
. 0 .= . device .OK
Bit:
. 0 .= . Rj .error
. 1 .= . Hardware .error
. .– .4 .= . reserved
.5 .– .7 .= . manufacturer-specific
Un-
signed .
8
D 1 RO 0
INPUT_FAULT_1 5
Input .malfunction: .Diagnosis .object .for .errors .that .con-
cern .SV_1
. 0 .= . Input .OK
Bit:
. 0 .= . underrange
. 1 .= . overrange
. .= . lead .breakage
. 3 .= . short .circuit
.4 .– .5 .= . reserved
.6 .– .7 .= . manufacturer-specific
Un-
signed .
8
D 1 RO 0
INPUT_FAULT_2 6
Input .malfunction: .Diagnosis .object .for .errors .that .con-
cern .SV_
. 0 .= . Input .OK
Bit .definition .see .INPUT_FAULT_1
Un-
signed .
8
D 1 RO 0
Rj_FAULT 67
Input .malfunction: .Diagnosis .object .for .errors .that .con-
cern .RJ .sensor .
. 0 .= . Input .OK
Bit:
. 0 .= . underrange
. 1 .= . overrange
. .= . lead .breakage
. 3 .= . short .circuit
Un-
signed .
8
D 1 RO 0
HW_ERROR 86
Diagnostic .bit .value .indicating .hardware .status
. 0 .= . hardware .OK
Bit:
. 0 .= . Input .power .supply .error
. 1 .= . Input .initialisation .error
. .= . Input .communication .error
. 3 .= . Internal .temperature .sensor .error
. 4 .= . Device .not .factory .calibrated
.5 .– .6 .= . reserved
. 7 .= . Watchdog .initiated .cold .start .occurred
Un-
signed .
8
D 1 RO 0
.8 .7 .Sensor .error .detection .parameters
Parameter
Rel.
Index
PA
Description Type Store Size
byte
RO /
R/W Min. Max. Default
SENSOR_WIRE_CHECK_1 7
Enables .lead .breakage .and .short .circuit .detection .for .
Sensor .1 .
List .of .valid .values:
0 .= .Lead .breakage .and .short .circuit .detection .enable .
1 .= .Lead .breakage .detection .enable, .short .circuit . .
detection .disable .
.= .Lead .breakage .detection .disable, .short .circuit . .
detection .enable .
3 .= .Lead .breakage .and .short .circuit .detection .disable .
Un-
signed .
8
SRC 1 R/W 3
SENSOR_WIRE_CHECK_2 8
Enables .lead .breakage .and .short .circuit .detection .for .
Sensor . .
Valid .values: .see .SENSOR_WIRE_CHECK_1 .
Un-
signed .
8
SRC 1 R/W 3
SENSOR_WIRE_CHECK_Rj 68
Enables .lead .breakage .and .short .circuit .detection .for .
RJ .Sensor .
Valid .values: .see .SENSOR_WIRE_CHECK_1 .
Un-
signed .
8
SRC 1 R/W 3
