Use the seal corresponding to the instrument:
l Process fitting GD: Tesnit seal in front of the thread
- or -
Seal the thread with teflon, hemp or a similar resistant seal material:
l Process fitting GN
à Screw IPT-1* into the welded socket. Tighten the hexagon on the
process fitting with a suitable wrench. Wrench size, see chapter
"D
imensional drawings".
Warning:
The housing must not be used to screw the instrument in! Applying
tightening force can damage internal parts of the housing.
Use the seal suitable for the respective process fitting. You can find
the components in the supplementary instructions manual "Welded
socket and seals".
Sealing/Screwing in
Sealing/Screwing in hy-
gienic fittings
Process pressure transmitter IPT-1* Vers. 3.0 - metalic sensor • 4 … 20 mA 13
4 Mounting
