10 WIKA operating instructions pressure transmitter model AC-1
14026285.01 11/2012 GB/D/F/E
GB
3. Specifications
Vacuum and +/- measuring range
bar Measuring range -1 ... +7 -1 ... +9 -1 ... +10 -1 ... +15
Overpressure limit 20 20 20 40
Burst pressure 25 25 25 50
Measuring range -1 ... +20 -1 ... +25 -1 ... +29 -1 ... +45
Overpressure limit 40 40 100 100
Burst pressure 50 50 120 120
Measuring range -0.5 ... +7 -0.5 ... +10
Overpressure limit 20 20
Burst pressure 25 25
psi Measuring range -30 inHg ... +100 -30 inHg ... +145 -30 inHg ... +200 -30 inHg ... +250
Overpressure limit 300 300 600 600
Burst pressure 375 375 750 750
Measuring range -30 inHg ... +300 -30 inHg ... +350 -30 inHg ... +400 -30 inHg ... +450
Overpressure limit 600 600 600 1,450
Burst pressure 750 750 750 1,800
Measuring range -30 inHg ... +500 -30 inHg ... +550 -30 inHg ... +600
Overpressure limit 1,450 1,450 1,450
Burst pressure 1,800 1,800 1,800
Vacuum tightness
Yes
