26
Choosing the installation location
(Unit : inch)
 When the upper part of the outdoor unit
and the air outlet is opposite the wall
 When the walls are blocking front and the rear side of the outdoor units
 When front and rear side of the outdoor unit is towards the wall
19
.7
o
r m
or
e
11.8 or more
19
.7
o
r m
or
e
11.8 or more
11
.8
o
r
m
or
e
59
.1
o
r
m
or
e
23.6 or more 23.6 or more
59.1 or
more
23.6 or
more
118.1 or
more
7.9 or
more
118.1 or
more
• If installation is done in inappropriate space, unit may generate sound and cause bad effect on the product.
• Installation must be done in level and in a place where vibration will not cause any effect.
Accessories
The following accessories are supplied with the air conditioner:
• The number of each accessory is indicated in parentheses.
Accessories in the indoor unit case
Accessories in the outdoor unit case
• The flare nuts are attached to the end of each pipe of an evaporator or a service port.
Use the nuts when connecting the pipes.
• The 2(3)-wire assembly cable is optional. If it is not supplied, use the standard cable.
• The drain plug and rubber leg are only included when the air conditioner is supplied without the assembly pipe as
seen in the picture.
Installation Plate (1)
 09/12/18/24
Installation Plate (1)
 36
Remote controller
(1)
Batteries for Remote
controller (2)
User’s & Installation
Manual (1)
2-wire
Assembly Cable (1)
3-wire
Assembly Cable (1)
Drain Plug (1) Rubber Leg (4)
