Figure 50 – M&G DuraVent DuraStack® User Manual
Page 29
29
Figure 50
Flip Top
3" Max
Expansion
3" Max
Expansion
Anchor Plate Ventilated
12" Long Length Minimum With Bellows
Bellow Joint
Wall Guide
Wall Support
12" Long Length Minimum With Bellows
Bellow Joint
Wall Guide
Wall Support
Suspension Band
12" Long Length Minimum With Bellows
Bellow Joint
Fixed Support
Suspension Band
Bellow Joint
Fixed Support
3" Max
Expansion
Fixed Support
Relief Valve
Fixed Support
Muffler
Engine
