Technical Specifications
11
11
7 Technical Specifications
Table 6 lists the technical specifications of the TP-145 and TP-146.
Table 6: Technical Specifications of the TP-145 and TP-146
TP-145 TP-146
INPUTS: Video: 1 XGA on a 15-pin HD connector
Audio: 1 Analog 3.5mm mini connector 1 RJ-45 LINE IN connector
OUTPUTS: 1 RJ-45 OUT TP connector Video: 1 UXGA on a 15-pin HD connector
Audio: 1 S/PDIF RCA connector
1 Analog 3.5mm mini connector
PORTS: 1 RS-232 bidirectional terminal block
RESOLUTION: Up to WUXGA, 1080p
MAX. OUTPUT
LEVEL:
Video: 1.6V
Audio: 2.3V
CONTROLS: EDID capture button Level: –7.5dB to +4.4dB,
EQ.: 0dB to +33dBm (130m) @ 50MHz
RS-232 BAUD RATE: Up to 19200kbps
RS-232 MODE: Full-duplex
BANDWIDTH: Audio: 20Hz – 20kHz @0.5dB
S/N RATIO: Audio: <–80dB
TOTAL GAIN: Audio:
Analog/analog: 0dB
Analog/SPDIF: –12dBFS
COUPLING: AC
TND+N: Audio: <0.01%
POWER SOURCE: 12V DC 180mA 12V DC 370mA
DIMENSIONS: 12.0cm x 7.8cm x 2.5cm (4.7" x 3.1" x 1.0") W, D, H
WEIGHT: 0.18kg. (0.4lbs.) approx.
ACCESSORIES: Power supply
