TP-125xl/TP-126xl - Technical Specifications
8
Technical Specifications
TP-125xl
TP-126xl
INPUTS:
1 UXGA on a 15-pin HD
connector (F)
1 Unbalanced stereo audio on a
3.5mm mini jack
1 Bidirectional RS-232 serial
port on a 3-pin terminal block
1 TP on an RJ-45 connector
OUTPUTS:
1 TP on an RJ-45 connector
1 UXGA on a 15-pin HD connector (F)
1 Digital audio on an RCA connector
1 Unbalanced stereo audio on a
3.5mm mini jack
1 Bidirectional RS-232 serial port on a
3-pin terminal block
VIDEO RESOLUTION:
Up to WUXGA, 1080p
MAX. OUTPUT LEVEL:
Video: 1.1V
Audio: 2.2V
AUDIO:
BANDWIDTH:
Audio: 20Hz-20kHz @
–3dB
S/N RATIO:
Audio: 84dB unweighted
COUPLING:
AC
TND+N:
Audio: 0.02% unweighted
TOTAL GAIN:
Analog/analog: 0dB
Analog/SPDIF:
–12dBFS
RS-232:
BAUD RATE:
9600, 19200bps
MODE:
Full-duplex
POWER CONSUMPTION:
12V DC 206mA
12V DC 235mA
TRANSMISSION DISTANCE:
Up to 250m (820ft)
OPERATING TEMPERATURE: 0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
–40° to +70°C (–40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12.1cm x 7.18cm x 2.48cm (4.76" x 2.83" x 0.98"), W, D, H
WEIGHT:
0.2kg (0.44lbs.) approx. each
ACCESSORIES:
Power supply
OPTIONS:
RK-
3T 19” rack adapter
