TP-125xl/TP-126xl - Connecting the TP-125xl and TP-126xl 9
9

The RS-232 controller, (for example, a laptop controller with an
RS-232 interface) to the RS-232 3-pin terminal block
 An unbalanced, stereo audio source, (for example, the audio output
from a laptop) to the Audio In 3.5mm mini jack
2. On the TP-126xl, connect:
 The UXGA Out 15-pin HD (F) connector to the video acceptor, (for
example, an AV display system)
 The RS-232 3-pin terminal block to the controlled device, (for example,
an AV display system)

The Audio Out Analog 3.5mm mini jack to the unbalanced, stereo
audio acceptor, (for example, an AV display system with speakers)
 The Audio Out S/PDIF RCA connector to the digital audio acceptor,
(for example, a DAT recorder)
3. Using STP cabling, connect the TP-125xl Line Out RJ-45 connector to the
TP-126xl Line In RJ-45 connector (see Section 2.3 ).
4. Connect the power adapters to the power sockets on the TP-125xl and
TP-126xl, and connect the adapters to the mains electricity (not shown in
Figure 5 ).
5. If necessary, adjust the level and equalization for an optimum picture (see
Section 6.2 ).
