6 Technical Specifications
Table 5 defines the technical specifications 1 of the 703xl / 705xl / 706xl
(using 100m UTP cable, unless stated otherwise):
Table 5: Technical Specifications of the 703xl / 705xl / 706xl
INPUTS: 703xl: 4 composite video 1Vpp/75 on BNC connectors; 4 Loop 1Vpp/75 on
BNC connectors
705xl: 1 composite video 1Vpp/75 on a BNC connector; 1 Loop 1Vpp/75 on
a BNC connector
706xl: 1 input on terminal block connectors; 1 Loop on terminal block connectors
OUTPUTS: 703xl: 4 terminal block connectors
705xl: 2 terminal block connectors
706xl: 2 composite video 1Vpp/75 on BNC connectors
BANDWIDTH (-3dB): (Industrial color video signal) at a distance of 1000 meters
Up to 12 MHz -3dB (broadcast quality signal) at a distance of 300 meters
703xl/705xl: 53 MHz –3dB at a distance of 100 meters
706xl: 108 MHz –3dB at a distance of 100 meters
DIFF. GAIN (Pair): 703xl/705xl: 0.08%
706xl: 0.03%
DIFF. PHASE (Pair): 703xl/705xl: 0.07 Deg
706xl: 0.03 Deg
K-FACTOR (Pair): 703xl/705xl: 3.1%
706xl: <0.1%
S/N RATIO (Pair): 703xl/705xl: 57dB
706xl: 73dB
CONTROLS: 703xl/705xl: Gain EQ.: 0 to 3.5dB @ 5MHz
706xl: Level: -5.3dB to +6dB; EQ.: 0dB to +8dB @ 5MHz
COUPLING: DC
POWER SOURCE: 703xl/705xl: 12 VDC, 200mA
706xl: 12 VDC, 78mA
703xl:
22cm x 18cm x 4.5 cm (8.7” x 7” x 1.7”) W, D, H (half 19”, 1U) DIMENSIONS:
705xl/706xl: 12 cm x 7.5 cm x 2.5 cm (4.7" x 2.95" x 0.98", W, D, H)
703xl:
1.2 kg. (2.65 lbs.) approx. WEIGHT:
705xl/706xl: .3 kg (0.66 lbs.) approx.
ACCESSORIES: Power supply, mounting bracket
OPTIONS: 19" rack adapter RK-80
1 Specifications are subject to change without notice
