Overview
KRAMER ELECTRONICS, LTD.
2
Receiver 1 constitutes a video line transmitter / receiver system. With the
706xl:
UTP (unshielded twisted pair) wiring is recommended
Using good quality cable, the system can maintain the bandwidth of an
industrial color video signal up to 1000 meters, and a broadcast quality signal
(as high as 12 MHz) up to 300 meters
A bandwidth of 30 MHz is easily achievable at shorter distances
Kramer twisted pair adapters are an excellent way to solve remote
monitoring requirements without using more costly coaxial cable or fiber, or
wireless transmission systems
A choice of 2 video line transmitters is available:
703xl Quad Video Line Transmitter
705xl Dual Video Line Transmitter
Both the 703xl and the 705xl work in conjunction with the 706xl receiver as a
high performance set, designed to transmit composite video signals over long
distances using common twisted pair cable.
The
703xl Quad Video Line Transmitter includes:
4 independent twisted pair outputs derived from 4 looped-through video
inputs
Individual gain control and cable equalization (EQ.) control for each
output
The 705xl Dual Video Line Transmitter includes:
2 independent twisted pair outputs derived from a single, looped-through
video input
Individual gain control and cable EQ. control for each output, for 2
separate, simultaneous paths of operation; or for two sets of twisted pair (TP)
wires
Achieving the best performance means:
Connecting only good quality connection cables, thus avoiding
interference, deterioration in signal quality due to poor matching, and elevated
noise levels (often associated with low quality cables)
Avoiding interference from neighboring electrical appliances that may
adversely influence signal quality and positioning your Video Line Transmitter
and/or a 706xl Dual Output Video Line Receiver in a location free from
moisture and away from excessive sunlight and dust
1 Its loop through input with a termination switch allows for branching
