Connecting a Video Line Transmitter/ Receiver System
KRAMER ELECTRONICS, LTD.
6
5.1 Connecting a Dual Video Line Transmitter/ Receiver System
To configure a Dual Video Line Transmitter / Dual Output Video Line
Receiver system, using two 705xl units and four 706xl units, as Figure 4
illustrates, do the following:
1. Connect a composite video source (for example, a VCR) to the CV IN
BNC connector on the first 705xl unit and release the TERM button to Hi-Z.
2. Connect the first 705xl unit’s LOOP connector to the CV IN connector on
the second 705xl unit and push in the Term button (on the second 705xl unit)
to 75 .
3. Connect the first
705xl unit’s OUTPUT 1 terminal block connectors to
the IN terminal block connectors on the “A1, A2” 706xl unit 1 .
4. Connect the first 705xl unit’s OUTPUT 2 terminal block connectors to
the IN terminal block connectors on the “B1, B2” 706xl unit 1 .
5. Connect the “A1, A2” 706xl unit’s LOOP terminal block connectors to
the IN terminal block connectors on the “A3, A4” 706xl unit 1 .
This creates transceiver connection A.
6. Connect the “B1, B2”
706xl unit’s LOOP terminal block connectors to
the IN terminal block connectors on the “B3, B4” 706xl unit 1 .
This creates transceiver connection B.
7. Connect the composite video outputs on up to four pairs of
706xl units to
their respective composite video acceptors, as follows:
On the “A1, A2” unit, OUT 1 to acceptor 1A; OUT 2 to acceptor 2A
On the “B1, B2” unit, OUT 1 to acceptor 1B; OUT 2 to acceptor 2B
On the “A3, A4” unit, OUT 1 to acceptor 3A; OUT 2 to acceptor 4A
On the “B3, B4” unit, OUT 1 to acceptor 3B; OUT 2 to acceptor 4B
8. Connect the power adapter on each unit to the electricity supply.
9. Adjust the output signal level and the cable compensation equalization
level individually, for each output, if required.
1 Connect “+ ” to “+”, and “-” to “-” between the terminal block connectors
