Connecting a Video Line Transmitter/ Receiver System

KRAMER ELECTRONICS, LTD.

8

5.2 Connecting a Quad Video Line Transmitter/ Receiver System

To configure a Quad Video Line Transmitter / Dual Output Video Line

Receiver system, using a

703xl unit and up to four 706xl units, as Figure 5

illustrates, do the following:
1. Connect up to 4 composite video sources (for example, 4 VCRs) to the 4

IN BNC connectors on the

703xl unit.

2. Connect up to 4 of the

703xl unit’s OUTPUT terminal block connectors

to the respective IN terminal block connectors

1

on each of the four

706xl units

(“A1, A2”, “B1, B2”, “C1, C2”, and “D1, D2”)

2

.

3. Connect the “A1, A2”

706xl unit’s LOOP terminal block connectors to

the IN terminal block connectors on the “A3, A4”

706xl unit

1

.

This creates transceiver connection A.
4. Repeat step 3 (above) connecting up to 3 additional pairs of

706xl units

1

.

This creates transceiver connections B (“B1, B2” to “B3, B4”), C (“C1, C2”

to “C3, C4”), and D (“D1, D2” to “D3, D4”).
5. Connect the composite video outputs on up to four pairs of

706xl units to

their respective composite video acceptors, as follows:

On the “A1, A2” unit, OUT 1 to acceptor 1A; OUT 2 to acceptor 2A
On the “B1, B2” unit, OUT 1 to acceptor 1B; OUT 2 to acceptor 2B
On the “A3, A4” unit, OUT 1 to acceptor 3A; OUT 2 to acceptor 4A
On the “B3, B4” unit, OUT 1 to acceptor 3B; OUT 2 to acceptor 4B
On the “C1, C2” unit, OUT 1 to acceptor 1C; OUT 2 to acceptor 2C
On the “D1, D2” unit, OUT 1 to acceptor 1D; OUT 2 to acceptor 2D
On the “C3, C4” unit, OUT 1 to acceptor 3C; OUT 2 to acceptor 4C
On the “D3, D4” unit, OUT 1 to acceptor 3D; OUT 2 to acceptor 4D

6. Connect the power adapter on each unit to the electricity supply.
7. Adjust the output signal level and the cable compensation equalization

level individually, for each output, if required.

1 Connect “+ ” to “+”, and “-” to “-” between the connectors
2 Figure 5 shows OUTPUTS 1 and 4 connected to the IN on 706xl units, “A1, A2” and “D1, D2”, respectively
