FC-340 - Overview
3 Overview
The FC-340 SDI Scaler/Embedder/Scan Converter is ideal as a broadcast-quality
video scaler and audio embedder/de-embedder for digital signals up to 3G
HD-SDI.
All mentions of SDI in this manual include signals up to and including 3G HD-SDI.
The FC-340 features:

A maximum data rate of 3Gpbs

1 SDI video input and 2 SDI video outputs

1 re-clocked, looping video output

1 composite video output

1 balanced audio output

2 AES/3id audio inputs and 2 AES/3id audio outputs
Note: Some machines may have AES/EBU printed instead of
AES-3id.

The option to select either the embedded audio or to embed two
independent audio groups
 Kramer reKlocking™ & Equalization Technology that rebuilds the digital
signal to travel longer distances

An LCD text display for easy configuration and operation
