FC-340 - Kramer Protocol
10 Kramer Protocol
The FC-340 supports the Kramer Protocol 3000.
The Protocol 3000 RS-232 communication protocol lets you control the machine
from any standard terminal software (for example, Windows
®
HyperTerminal
Application).
10.1 Protocol 3000 Syntax
Host message format:
Start Address
(optional) Body Delimiter
# Destination_id@ message CR
Simple command (commands string with only one command without addressing):
start body delimiter
# Command SP Parameter_1,Parameter_2,…
CR
Commands string (formal syntax with commands concatenation and addressing):
# Address@ Command_1
Parameter1_1,Parameter1_2,… |Command_2
Parameter2_1,Parameter2_2,… |Command_3 Parameter3_1,Parameter3_2,…
|…CR
Device message format:
Start Address (optional) Body Delimiter
~ Sender_id@ message CR LF
Device long response (Echoing command):
Start Address
(optional) Body Delimiter
~ Sender_id@ command SP
[
param1 ,param2
…]
result CR LF
CR = Carriage return (ASCII 13 = 0x0D)
LF = Line feed (ASCII 10 = 0x0A)
SP = Space (ASCII 32 = 0x20)
