Z USB3.0 / eSATA Combo Drive Enclosure
for SATA or IDE Hard drive or Optical drive

Model: ZESSIU3CS

User’s Guide

FCC Warning Statement

This equipment has been tested and found to comply with the limits for a cl ass B digital
device pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy. If n ot installed and
used in accordance with the instructions, it may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If the equipment does cause harmful interf erence to radio or
television reception, which can be determined by turning the equipment on and off, the user
is encouraged to try and correct the interference by one or more of the following
suggestions.
Reorient or relocate the receiving antenna
Increase the distance between the equipment and the receiver
Connect the equipment to a different power outlet other than the one where receiver is
connected
Consult a certified television or radio technician

TECHNICAL SUPPORT
Phone:

408-453-6212

Hours:

8:30 am - 6:00 pm PST

Email:

http://www.addonics.com/support/query/

Enclosure Overview

Removing the front panel

You can remove the front panel of the enclosure to
access the drive drawer of the optical drive.

Step 1
Loosen the two screws from the rear panel. Pull out the interior tray from the
enclosure.

Step 2

A.

Installing a 3.5” SATA hard drive

Slide in the 3.5”
SATA hard drive
and secure on the
tray using screws.

Screw 1

Screw 2

Power
Connector

Switch

Fan

eSATA Port

SATA hard
drive
