Addonics Technologies AAT18ZIF25 User Manual

User guide, Installation guide

background image

Installation Guide

Note: The master and slave pin settings on the 50-pin IDE connector is disabled.

T E C H N O L O G I E S

User Guide

Toshiba 1.8"ZIF to 2.5"

IDE Hard Drive Connector

Converter

(AAT18ZIF25)

2.5” IDE Connector

ZIF Connector

Pin 1

Pin 1

Technical Support

If you need any assistance to get your unit functioning properly, please have your

product information ready and contact Addonics Technical Support at:

Hours: 8:30 am - 6:00 pm PST

Phone: 408-453-6212

Email: http://www.addonics.com/support/query/
