ADDONICS TECHNOLOGIES

Model: AEMK35CB

Installation Guide

1.

Connect the other end of the dual connector IDE
ribbon cable to the IDE connector on the Desktop
Card Drive reader.

2.

Connect one end of the dual connector IDE ribbon
cable to the IDE connector on the PCI controller.

3.

Plug-in the PCI controller on a PCI bus slot.

4.

Mount the Desktop Card Drive reader on a 3.5”
drive bay. Using the screws provided, secure the
reader to the drive bay.

Types of Bus Slots

Note:

The AEMK35CB PCI controller connects to a PCI
bus slot.

Product Features

Kit includes Card Drive, PCI controller and
connecting cables

Card Drive Installs into standard 3.5" drive bay to
be accessible from the front of the computer, just
like a floppy drive!

Supports both 32-bit Cardbus and 16-bit PCMCIA
devices

Compatible with any CardBus/ PCMCIA device
such as Wireless Broadband cards, Wireless
modem, Panasonic P2 card, ATA Flash, sound
card, video capture card, Addonics family of
CardBus adapters

Drive activity LED on Card drive

Simple plug and play, no drivers required

Compatible with Windows XP

RoHS Compliant

TECHNICAL SUPPORT

Email:

http://www.addonics.com/sales/query/

Internet:

http://www.addonics.com

Technical Support (8:30 am to 6:00 pm PST)
Phone: 408 433-3855
Email:

http://www.addonics.com/support/query/

Drive activity LED

PCI Controller

Desktop Card Drive reader
Cardbus and PCMCIA
devices slot

Dual connector IDE
ribbon cable

Eject Button

PCI

PCI
