ADDONICS TECHNOLOGIES
Model: ADSAUSPCB



Hardware Installation:

Step 1. Connect the 2-pin power cable to the 2-pin power connector on the adapter. Be sure

to connect the red wire to the pin with +5V label.

Step 2. Connect a SATA cable to the SATA connector on the adapter and the other

end to the SATA device.

Step 3. Connect a USIB cable to the USIB connector on the adapter and the other

end to the host

TECHNICAL SUPPORT

Email:

http://www.addonics.com/sales/query/

Internet:

http://www.addonics.com


Technical Support (8:30 am to 6:00 pm PST)
Phone:

408 433-3855

Email:

http://www.addonics.com/support/query/

ADDONICS TECHNOLOGIES
Model: ADSAUSPCB



Hardware Installation:

Step 1. Connect the 2-pin power cable to the 2-pin power connector on the adapter. Be sure

to connect the red wire to the pin with +5V label.

Step 2. Connect a SATA cable to the SATA connector on the adapter and the other

end to the SATA device.

Step 3. Connect a USIB cable to the USIB connector on the adapter and the other

end to the host

TECHNICAL SUPPORT

Email:

http://www.addonics.com/sales/query/

Internet:

http://www.addonics.com


Technical Support (8:30 am to 6:00 pm PST)
Phone:

408 433-3855

Email:

http://www.addonics.com/support/query/

USIB Connector

SATA Port

Drive Activity
LED Connection

2-Pin Power
Connector

Correct way of
connecting the 2-pin power cable
to the 2-pin connector on the
adapter

Red wire

Black wire

USIB Connector

SATA Port

Drive Activity
LED Connection

2-Pin Power
Connector

Correct way of
connecting the 2-pin power cable
to the 2-pin connector on the
adapter

Red wire

Black wire
