Kramer Electronics RC-7B User Manual

Page 14

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Using Your Media / Room Controller

5.2 Using the Macro Buttons

Pressing any button initiates a macro sequence

, during which the button

blinks (as programmed by the system integrator).
If during the macro sequence the button blinks faster than usual

, this indicates

that a malfunction has been detected

and the

RC-7B / RC-7BE exits the macro

sequence.

To solve the problem, summon technical help

If you want to stop a macro sequence, press and hold that button for 5

seconds. The sequence will come to an end. You can resume operation by

pressing any of the buttons

. The unit will carry out the macro sequence

commands from the beginning.

5.3 An Example of Operating the RC-7B / RC-7BE

Figure 8 shows an example of how to operate the

RC-7B / RC-7BE:

Power down the projector, DVD player and the video player.

OFF

Select the DVD input on the projector and play the DVD.

DVD

Select the PC input on the projector and resume the slide show.

Select the PC input on the projector and show the last few slides of the

presentation.

Select the VCR input on the projector and show the video film.

VCR

Figure 8: RC-7B / RC-7BE Operation Example

1 The macro sequence can be carried out instantly or can take a while, depending on the delay times included in the sequence
2 Six times per second, as compared with twice per second during normal operation
3 For example, when pressing ON to power up the projector while the projector is still in the power down process
4 Including the button you kept pressed to stop the macro sequence
