Your RC-52N

3

4 Your RC-52N

This section describes the front (see

Section 4.1

) and the rear (see

Section

4.2

) panels of the RC-52N.

4.1 The RC-52N Front Panel

The RC-52N is available in three versions (see

Figure 1

): 80mm and 86mm

for Europe and a version for the United States:

United States

Europe (80mm)

Europe (86mm)

Figure 1: RC-52N Front Panel for Europe (80 and 86mm) and the United States
