Your VS-6YC s-Video 4x4 Matrix Switcher
4
Table 1: Features and Functions of the VS-6YC s-Video 4x4 Matrix Switcher
#
Feature
Function
1
POWER Switch
Illuminated switch for turning the unit ON or OFF
2
INPUT SELECTOR Router Knobs
1
Select the input to switch to the output
2
(from A to D)
3
7-segment Display
Displays the input switched to the output (marked above
each input)
4
AUDIO
OUTPUTS
RCA Connectors
Connect to the audio acceptors
3
(from A to D)
5
Y/C 4p Connectors
Connect to the s-Video acceptors (from A to D)
6
VIDEO
OUTPUTS
4
CV BNC Connectors Connect to the composite video acceptors (from A to D)
7
AUDIO
INPUTS
RCA Connectors
Connect to the audio sources
3
(from 1 to 4)
8
Y/C 4p Connector
Connect to the s-Video sources (from 1 to 4)
9
VIDEO
INPUTS
5
CV BNC Connector
Connect to the composite video sources (from 1 to 4)
10 Power Connector with Fuse
AC connector enabling power supply to the unit
1 Each Router Knob lets you select which input is switched to which output
2 An input may be switched to one or more outputs
3 Supports unbalanced stereo audio signal types
4 For each channel (A to D), either a composite video or an s-Video acceptor can be connected
5 For each channel (1 to 4) either a composite video or an s-Video source can be connected
