Technical Specifications
8
7 Technical Specifications
Table 2 includes the technical specifications:
Table 2: Technical Specifications
1
of the VS-6YC s-Video 4x4 Matrix Switcher
INPUTS:
4 video, 1Vpp/75 composite on BNC connectors;
4 s-Video, 1Vpp/75 (Y), 0.3Vpp/75 (C) on 4p connectors;
4 audio stereo, 1Vpp/100 on RCA connectors
OUTPUTS:
4 video, 1Vpp/75 composite on BNC connectors;
4 s-Video, 1Vpp/75 (Y), 0.3Vpp/75 (C) on 4p connectors;
4 audio stereo, 1Vpp/100 on RCA connectors
MAX. VIDEO OUTPUT:
2Vpp/75
VIDEO BANDWIDTH (-3DB): 37MHz
AUDIO BANDWIDTH (-3DB): 22kHz
DIFF. PHASE:
0.53 Deg.
VIDEO S/N RATIO:
72dB
VIDEO S/N RATIO:
78dB
VIDEO CROSSTALK:
-65dB (SYNC), -42dB (C)
CONTROL:
4 rotary control knobs
AUDIO THD:
0.1%
POWER SOURCE:
230VAC, 50/60Hz (115VAC USA) 12VA
DIMENSIONS:
19” (W), 7” (D), 1U (H) rack mountable
WEIGHT:
2.8kg (6.2lbs.) approx.
ACCESSORIES:
Power cord
1 Specifications are subject to change without notice
