4 VS-42HN - Overview
3 Overview
The VS-42HN is a high quality 4x2 matrix switcher for HDMI signals. It reclocks and
equalizes the signals and can route any input to any or all outputs simultaneously.
In particular, the VS-42HN features:

Up to 6.75Gbps data rate (2.25Gbps per graphics channel)
Suitable for resolutions up to UXGA and 1080p at 60Hz

Support for HDCP (High Definition Digital Content Protection)

HDMI support for 3
D, Deep Color, x.v.Color™, Lip Sync

3D pass-through

Support for up to 7.1 multi channel audio

I- EDIDPro™ Kramer Intelligent EDID Processing™ – Intelligent EDID
handling and processing algorithm ensures Plug and Play operation for
HDMI systems
 Kramer reKlocking™ and Equalization Technology that rebuilds the digital
signal to travel longer distances

A lock button to prevent unwanted tampering with the buttons on the front
panel

Preset memory locations for quick access to common configurations

Support for Kramer Protocol 2000 and Protocol 3000
You can control the VS-42HN using the front panel buttons, or remotely via:

RS-232 serial commands transmitted by a PC, touch screen system or other
serial controller

The Kramer RC-IR3 infrared remote control transmitter

A PC connected to the Ethernet port on the device via a LAN

An external remote IR receiver (optional), see Section
3.2
3.1 Defining the VS-42HN 4x2 HDMI Matrix Switcher
Figure 1 and Figure 2 define the VS-42HN.
