Technical Specifications
7
7
7 Technical Specifications
Table 2 includes the technical specifications 1
Table 2: Technical Specifications of the VS-33Vxl
.
INPUTS: 3 composite video, 1Vpp/75Ω on BNC connectors
OUTPUT: 1 composite video, 1Vpp/75Ω on a BNC connector
MAX. VIDEO OUTPUT: 1.8Vpp/75Ω
VIDEO BANDWIDTH (-3dB): 46MHz
DIFF. GAIN:
1.25%
DIFF. PHASE: 0.52°
K-FACTOR: <0.05%
VIDEO S/N RATIO: 73dB
SWITCHING: Vertical interval
CROSSTALK: -44dB@5MHz
POWER SOURCE: 5VDC 22mA
DIMENSIONS: 12cm x 6.95cm x 2.44cm (4.72" x 2.74" x 0.96", W, D, H)
WEIGHT: 0.3kg (0.66lbs.) approx.
ACCESSORIES: 5VDC power supply
OPTIONS:
19” Rack Adapters, VA-100P-5 5V DC Power Supply
6F
2
1 Specifications are subject to change without notice
2 An efficient ten-outlet universal switching power supply that can supply 5V DC at up to 8A
