AVerMedia Technologies 1500 MCE - Manual (Page 21)

Chapter 3
TV
-17-
The 16-channel preview function can display 16 TV channels on-screen at the same
time. You can see clearly which TV programs are currently showing on these channels.
To preview the channels:
18. Click the 16 Channel Preview button .
19. The screen will be gradually filled up with 16 TV channels, starting from the
currently selected channel.
20. Click a channel to view it only and freeze the other channels.
21. To display a channel on the TV Monitor window, select any one of the 16
channels on-screen and double-click the left mouse button on that channel, or
use the arrow
↑,↓, ← , or → buttons of your keyboard then press Enter. You
will then be tuned in to that channel. (Or, Click the right mouse button or press
ESC to return to the originally selected TV channel.)
Selecting Between TV and External Video
If you want to watch video from an external source such as a VCR or camcorder,
click the
Change Video Source button to switch between watching TV, a
Composite video source, and S-Video source.
Setting the Video Format of External Video
To set the video format used by the external video source, do the following:
22. Click the Setup button and click the Channel tab.
23. From the Video Source drop-down list, choose the type of external source:
Composite or S-Video.
24. From the Video Standard drop-down list, select the proper video format.
