VS-24xl - Technical Specifications
9
6 Technical
Specifications
INPUTS:
2 composite video 1Vpp/75
Ω on BNC connectors
2 balanced stereo audio +4dBu on detachable terminal
block connectors
OUTPUTS:
1 composite video 1Vpp/75
Ω on a BNC connector
1 balanced stereo audio +4dBu on a detachable terminal
block connector
MAX. OUTPUT LEVEL:
Video: 2.1Vpp @100% color bars
VIDEO BANDWIDTH (-3dB):
620MHz
AUDIO BANDWIDTH (-3dB):
>65MHz (suitable for S/PDIF)
DIFF. GAIN:
0.03%
DIFF. PHASE:
0.03 Deg.
K-FACTOR: <0.05%
S/N RATIO:
Video: 74dB; Audio: 71dB weighted
CROSSTALK (all hostile):
Video: -56.3dB Audio: -65.8dB @1kHz
CONTROLS:
Video level: -0.8 to +6.4dB; EQ: 0 to +12.8dB
AUDIO THD + NOISE:
0.019%
AUDIO 2nd HARMONIC:
0.002%
POWER CONSUMPTION:
12V DC, 90mA
OPERATING TEMPERATURE:
0° to +55°C (32° to 131°F)
STORAGE TEMPERATURE:
-45° to +72°C (-49° to 162°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
22cm x 18cm x 4.5cm (8.7” x 7” x 1.7”) W, D, H
(half 19”, 1U)
WEIGHT:
1.2kg (2.65lbs) approx.
ACCESSORIES:
12V power supply, RK-1
Specifications are subject to change without notice at
