VP-443 - Controlling the VP-443 15
15
Parameter Function
DELAY Select the audio delay time: OFF, 40ms, 110ms and 150ms
SOUND Select the sound options: ON, MUTE
MUTE FOLLOWS Select the action that will be followed by mute:
INDEPENDENT: the audio muting is independent of the FREEZE and
BLANK functions
FREEZE
BLANK
FREEZE/BLANK: when freezing or blanking the video, the audio will
be muted (the MUTE function follows the FREEZE and the BLANK
functions)
HDMI AUDIO IN Select:
AUTOMATIC: the embedded audio on the HDMI input is selected for
an HDMI signal, or the analog audio input is selected if the input is not
HDMI (for example, for a DVI input signal)
EMBEDDED: the embedded audio in the HDMI signal is selected
ANALOG: the analog audio input is selected
HDMI AUDIO IN is enabled only when one of the HDMI inputs is selected
6.2.4 The OSD Menu
Parameter Function
H POSITION Set the horizontal position of the OSD (from 0 to 100)
V POSITION Set the vertical position of the OSD (from 0 to 100)
TIMER Set the timeout period in seconds (from 5 to 100)
BACKGROUND Set the OSD background between 0 (solid black) and 8 (transparent)
DISPLAY Select the information shown on the screen during operation:
ON: the information is shown permanently
OFF: the information is not shown
INFO: the information is shown for a few seconds
6.3 Connecting to the VP-443 via RS-232
You can connect to the VP-443 via an RS-232 connection using, for example, a PC.
Note that a null-modem adapter/connection is not required.
To connect to the VP-443 via RS-232 Connect the RS-232 9-pin D-sub rear panel
port on the product unit via a 9-wire straight cable (only pin 2 to pin 2, pin 3 to pin 3,
and pin 5 to pin 5 need to be connected) to the RS-232 9-pin D-sub port on your PC
6.4 Connecting the VP-443 via the ETHERNET Port
To connect and configure the Ethernet port of the VP-443, refer to the ETHERNET
Configuration (Lantronix) GUIDE on our Web site:
http://www.kramerelectronics.com/support/product_downloads.asp
