Page 17

VP-443 - Controlling the VP-443

6.2.1

The MAIN MENU

Mode

Function

CONTRAST

Set the contrast (the range and default values vary according to the input signal)

BRIGHTNESS

Set the brightness (t

he range and default values vary according to the input

signal)

FINETUNE

Optimize the image quality (see

Section

6.2.2

)

COLOR

Set the red, green and blue shades (0 to 100, default 48, 48 and 52 respectively)

SIZE

Select the size of the display: FULL, PANSCAN, OVERSCAN, UNDER1,
UNDER2, LETTER BOX, BEST FIT (default, FULL)

UNDER1 refers to an underscan of 6%; UNDER2 refers to an underscan of 9%

SOURCE

Select the source: (default VGA)

Source input

Appears as:

Source input

Appears as:

CV 1

CV1

VGA 2

PC2

CV 2

CV2

HDMI 1

HDMI1

COMP 1

YPBPR1

HDMI 2

HDMI2

COMP 2

YPBPR2

HDMI 3

HDMI3

VGA 1

PC1

HDMI 4

HDMI4

OUTPUT

Select the output resolution from the menu (default NATIVE):

Output resolution:

Appears as:

Output resolution:

Appears as:

NATIVE

1080p @50Hz

1080P50

640x480

VGA

1366x768

WXGA

800x600

SVGA

1680x1050

WSXGA

1024x768

XGA

1920x1200

WUXGA

1280x1024

SXGA

1280x800

1600x1200

UXGA

1440x900

WSXGA+

480i

480I

1400x1050

SXGA+

480p

480P

1600x900

720p @60Hz

720P60

2048x1080 @50Hz

2048x1080/50Hz

1080i @60Hz

1080I60

2048x1080 @60Hz

2048x1080/60Hz

1080p @60Hz

1080P60

[email protected]

480I59

576i

576I

[email protected] Hz

480P59

576p

576P

[email protected]

720P59

720p @50Hz

720P50

[email protected]

1080I59

1080i @50Hz

1080I50

[email protected]

1080P59

NATIVE - Select NATIVE to select the output resolution from the EDID of the
connected HDMI monitor

AUDIO

Adjust audio parameters (see

Section

6.2.3

)

OSD

Set the OSD parameters: H POSITION, V POSITION, TIMER, BACKGROUND
and DISPLAY (see

Section

6.2.4

)

HDCP ON
INPUT

Select the HDCP option for the HDMI input: either ON (the default) or OFF.
Setting HDCP support to enabled (ON) on the HDMI input allows the source
to transmit a non-HDCP signal if required (for example, when working with a
Mac computer)

HDCP ON
OUTPUT

Select FOLLOW INPUT or FOLLOW OUTPUT to define whether the HDCP
will follow the input or the output
When FOLLOW INPUT is selected, it changes its HDCP output setting (for
the HDMI output) according to the HDCP of the input. This option is
recommended when the HDMI output is connected to a splitter/switcher
When FOLLOW OUTPUT is selected, the scaler matches its HDCP output to
the HDCP setting of the HDMI acceptor to which it is connected
