Page 8
8
K R A M E R
E lectron ics
MATRIX ROUTING SWITCHER
2
nd
BYTE:
Bit 7 – Defined as 1.
D6…D0 – “INPUT or DATA”.
When switching (ie. instruction codes 1 and 2), the INPUT (MSB + 7 bits) is set as the input
number which is to be switched. For other operations, these bits are defined according to the
table.
3
rd
BYTE:
Bit 7 – Defined as 1.
A6…A0 – “OUTPUT or ADRESS”.
When switching (ie. instruction codes 1 and 2), the OUTPUT (7 bits) is set as the output
number which is to be switched. For other operations, these bits are defined according to the
table.
4
th
BYTE:
Bit 7 – Defined as 1.
Bit 6 – Most Significant Bit (Bit A7) of the output byte.
Bit 5 – Most Significant Bit (Bit D7) of the input byte.
L4…L0 – LAYER NUMBER.
Used to address layers in a system via their layer numbers. When several layers (video,
audio, YC, YUV, RGBHV) are controlled from a single serial port in a same machine, they
are usually configured separately having an individual layer number.
TABLE OF INSTRUCTION CODES FOR PROTOCOL “MX06”
Notes: All values in the table are decimal, unless otherwise stated as Hexadecimal (xxh).
2.1.1.1 INSTRUCTION
DEFINITION FOR SPECIFIC INSTRUCTION
Layer Note
SEND
REPLY
Hex Dec Hex Dec
DESCRIPTION
INPUT
OUTPUT
Hex
01h
1
41h
65
VIDEO
01h
1
01h
1
41h
65
Y / C
02h
1
01h
1
41h
65
YUV
03h
1
01h
1
41h
65
RGBHV
05h
1
02h
2
42h
66
SWITCH
AUDIO
Set equal to video input which
is to be switched
(0 = disconnect)
Set equal to video output
which is to be switched
(0 = to all the outputs)
01h
1
03h
3
43h
67
STORE STATUS
Set as SETUP#(0-7)
0 - To store
1 - To delete
01h
04h
4
44h
68
RECALL STATUS
Set as SETUP#(0-7)
0
01h
05h
5
45h
69
VIDEO
01h
2
05h
5
45h
69
Y / C
02h
1
05h
5
45h
69
YUV
03h
1
05h
5
45h
69
RGBHV
05h
1
06h
6
46h
70
REQUEST
STATUS OF
AN
OUTPUT
AUDIO
0
Equal to output number whose
status is requested
01h
2
10h
16
50h
80
ERROR / BUSY
0
0 - Error
1 - Invalid Instruction
2 - Out of range
3 - Machine busy
4 - No card
5 - Adress out of range
6 - Data out of range
7 - Machine busy
01h
3
11h
17
51h
81
RESERVED
- - - -
- - - -
01h
