14 SID-X2N - Operating the SID-X2N
7 Operating the SID-X2N
This chapter describes the operating procedures of the SID-X2N and comprises:

Selecting an input manually (see Section
7.1
)

Locking the EDID (see Section 7.2 )
Powering up the SID-X2N recalls the last settings (that is, the configuration of the
device when it was powered down) from the non-volatile memory.
7.1 Selecting an Input Manually
To select an input, press the INPUT SELECT button repeatedly until the required
input is active as indicated by the associated LED.
Note: When the button is lit it is inactive and pressing the button will not activate
the input
7.2 Locking the EDID
To prevent the stored EDID (either default or read from a device) from being
overwritten, set DIP-switch 5 to ON (see Section
8.1
).
Note: The device must be power-cycled after you change this DIP-switch.
