Technical Specifications
9
6 Technical Specifications
Table 2 includes the technical specifications:
Table 2: Technical Specifications
1
of the VP-32K 3x1 PC / Audio Switcher
INPUTS:
3 UXGA on 15-pin HD connectors
3 balanced stereo audio 10k on 5-PIN terminal block connectors
OUTPUTS:
2 UXGA on 15-pin HD connectors
2 balanced stereo audio on 5-PIN terminal block connectors
MAX. OUTPUT LEVEL: VIDEO: 2.3Vpp
AUDIO: 6.8Vpp
BANDWIDTH (-3dB):
VIDEO: 420MHz
AUDIO: >100kHz
DIFF. GAIN:
0.03%
DIFF. PHASE:
0.03 deg
K-FACTOR:
<0.05%
S/N RATIO:
VIDEO: 72dB @5MHz
AUDIO: 88dB @1kHz
CROSSTALK (all hostile): VIDEO: –54dB
AUDIO: –77dB @1kHz
CONTROLS:
Front panel push buttons, contact closure remote control (on rear
panel)
COUPLING:
VIDEO: DC
AUDIO: Input: AC; Output: DC
AUDIO THD + NOISE:
0.009%
AUDIO 2nd HARMONIC: 0.001%
POWER SOURCE:
5V DC 210mA
DIMENSIONS:
21.46cm x 18cm x 4.36cm (8.45" x 7" x 1.72") W, D, H.
WEIGHT:
1.1kg (2.4lbs) approx.
ACCESSORIES:
Power supply
OPTIONS:
19" rack adapters
1 Specifications are subject to change without notice
