SPECIFICATIONS
VM-1110
VM-1610
VM-5AD
VM-80A
Configuration
1:10 or 2x1:5
1:10 or 2x1:5
1:5
1:8 or 2x1:4
Input Type
2 balanced audio
2 stereo balanced
audio
1 audio-balanced
mono, or unbalanced
stereo.
MIC state:
1 balanced mono Mic
or unbalanced stereo
Mic - 5mV/10kohm.
2 stereo audio balanced
Input
Connections
Female XLR
connectors
Terminal block
connectors
Female XLR
connectors
Terminal block
connectors
Input Level
+4dBm 50kohm
Up to
+24dBm/50Kohm
Up to
18Vpp/50Kohm MIC
state: 5mV/10kohm
+4dBm, 100kohm
Output Type
10 balanced audio
(5 stereo balanced
audio)
10 (or 2x5) stereo
balanced audio
5 mono balanced or
stereo unbalanced
audio
8 (or 2 x 4) stereo
balanced audio
Output
Connector
Male XLR
connectors
Terminal block
connectors
Male XLR
connectors
Terminal block
connectors
Output Level
+4dBm/50ohm
Up to
+24dBm/50ohm
Up to 20Vpp/50ohm +4dBm, 49ohm
Output
Coupling
AC
AC
AC
AC
Audio S/N Ratio >95dB@1Vpp
>92dB@1Vpp
>88dB@1Vpp
100dB@1Vpp
Audio
Bandwidth
10-100kHz, -3dB
10-100kHz, -3dB
10-80kHz, -3dB
10-20kHz, -1dB
Channel
Matching
60dB
60dB
>60dB
-65dB
Max audio
Output
>20Vpp
26Vpp
20Vpp
20Vpp
Audio THD
<0.1% at 1kHz
<0.011% at 1kHz 0.011% at 1kHz
<0.02% at 1kHz
Gain Range
0.5 to 9.4dB
0.5dB to 9.5dB
15.5dB to 35.6dB
0.2 to 5.8dB
Crosstalk
-62dB
-84.5dB
NA
-60dB
Controls
Front selector
switches for 1:10 or
2x1:5 operation
Front panel selectors
for 1:10 or 2x1:5
operation(4 trimmers
- two for each input
channel)
Front panel
stereo/balance and
Mic/line pushbuttons
Front panel selectors
for 1:8, 2x1:4,
operation, 4 front
accessible balanced
gain trimmers
Dimensions
(W, D, H)
48.3 x 17.8 x
4.5(cm)
19" x 7" x 1U
48.3 x 17.8 x
4.5(cm)
19" x 7" x 1U
24.5 x 18 x 4.5 (cm)
9.6" x 7" x 1.8"
22 x 18 x 4.5 (cm)
8.7 " x 7" x 1.8"
Weight
2.5 kg (5.5 lbs.)
Approx.
2.6 kg (5.7 lbs.)
Approx.
1.2kg. (2.7 lbs.)
Approx.
1.2kg. (2.7 lbs.)
Approx.
Power
Consumption
3.2VA
21VA
3.4VA
6.7VA
Power Source
230/115VAC,
50/60Hz(115V
U.S.A.)
230/115VAC,
50/60Hz(115V
U.S.A.)
230/115VAC,
50/60Hz(115V
U.S.A.)
230/115VAC,
50/60Hz(115V
U.S.A.)
