8 VM-114H - Connecting the VM-114H
4 Connecting the VM-114H
Always switch off the power to each device before connecting it to your
VM-114H. After connecting your VM-114H, connect its power and then
switch on the power to each device.
To connect the VM-114H as illustrated in the example in Figure 2 :
1. Connect the HDMI source (for example, a DVD player) to the IN 1 (HDMI)
connector.
2. Connect the CAT 5 TP source (for example, a PT-571 HDMI Line
Transmitter, VM-114H2C or VM-1114H4C) to the IN 2 (CAT5) connector.
3. Connect the HDMI OUT connectors to up to four HDMI display devices (for
example, plasma displays or LCD TVs)
4. (Optional) Connect a PC via RS-232 to the RS-232 port on the VM-114H
(see Section
5.3
).
5. Connect the power adapter to the power socket on the VM-114H and to the
mains electricity.
6. (Optional) Press the EDID READ button to acquire or change the EDID
information (see Section
5.1
).
i
