VoiceBox 4 I/OP
User Manual
Attero Tech LLC 2010
Page 4
614-00008-02
2– Installation
Figure 3 – VoiceBox 4 I/OP Connectors and Indicators
1
Power LED
2
Power Socket – Use with optional 12 V DC wall wart only.
3
Serial Bridge interface connector
4
CobraNet Ethernet interface connector and indicators
5
4 x Balanced audio inputs and associated mic/line and phantom power switches
6
4 x Balanced Audio outputs
