Bell & Gossett P2001406C Series e-1510 Centrifugal Pumps - Manual (Page 12)

Product Description
General description
Description
The pump is a centrifugal, frame-mounted pump. The following pump features make it
easy to install, operate, and service:
• High efficiency
• Rugged stainless steel-fitted construction
• Foot-mounted volute with back pullout bearing frame
• Center drop-out coupling
• Regreasable bearings
Intended applications
WARNING:
California Proposition 65 warning! This product contains chemicals known to the state of
California to cause cancer and birth defects or other reproductive harm.
The pump is intended for use with these pumped fluids:
• Unheated domestic and fresh water
• Boiler feed water
• Condensate
• Hydronic cooling or heating
• Benign liquids
• Pressure boosting
• General liquid transfer
Rotation
Pump rotation is clockwise when viewed from the back of the motor. An arrow is also
located on the pump to show the direction of rotation.
Operational specifications
Mechanical seal specifications
Seal type/
Parameter
Standard seal,
BUNA/Carbon/
Ceramic
Optional seal,
EPR/Carbon /
Tungsten
Carbide
Optional seal,
FKM/Carbon /
Ceramic
Optional seal,
EPR/Silicon
Carbide/Silicon
Carbide
Optional seal,
EPR/Carbon /
Tungsten
Carbide with
external
flush 1,3,4
Packing 2
Operating
temperature
range, °F (°C)
-20 to 225 (-29
to 107)
-20 to 250 (-29
to 121)
-10 to 225 (-23
to 107)
-20 to 250 (-29
to 121)
-20 to 250 (-29
to 121)
0 to 200 (-18
to 93)
pH range limits 7.0 to 9.0 7.0 to 11.0 7.0 to 9.0 7.0 to 12.5 7.0 to 9.0 7.0 to 9.0
Resistance to
dissolved
solids
Low Low-Medium Low Medium-High Low-Medium Medium
Maximum
glycol/water
concentration
50/50% 50/50% 50/50% 60/40% 50/50% Not
recommended
Product Description
10 Series e-1510 Installation, Operation, and Maintenance Manual
