Numbering system definitions

First character: Variable or constant speed
V = variable speed

X = XLS variable speed

C = constant speed

Second character: Number of pumps
2, 3, or 4

Third character: Pump type and size
H9 = 9SH

HA = 10SH

HB = 11SH

H4 = 4SH

H7 = 7SH

H5 = 5SH

H8 = 8SH

H6 = 6SH

HC = 24SH

HD = 25SH

HE = 22SH

HF = 27SH

HG = 23SH

HH = 28SH

—

Fourth character: Header size
C = 3 in.

E = 6 in.

G = 10 in.

D = 4 in.

F = 8 in.

H = 12 in.

Fifth character: Supply voltage
2 = 208 V / 1 PH / 60 Hz

6 = 460 V / 3 PH / 60 Hz

3 = 230 V / 1 PH / 60 Hz

7 = 575 V / 3 PH / 60 Hz

4 = 208 V / 3 PH / 60 Hz

8 = 380 V / 3 PH / 60 Hz

5 = 230 V / 3 PH / 60 Hz

9 = 380 V / 3 PH / 50 Hz

Sixth character: HP rating
A = 1/2

E = 2

J = 10

N = 30

T = 75

B = 3/4

F = 3

K = 15

P = 40

U = 100

C = 1

G = 5

L = 20

R = 50

V = 125

D = 1-1/2

H = 7-1/2

M = 25

S = 60

W = 150

Seventh character: Trim

9SH

10SH

11SH

4SH

7SH

5SH

8SH

6SH

22SH

23SH

24SH

25SH

27SH

28SH

6-5/8

8-27/64 10-3/32 6-3/4

8-1/4

6-7/8

8-1/4

7-5/16 9-1/16 9-1/16 9-7/8

9-7/8

10-3/8 10-5/8

6-7/16 8-1/16 9-17/32 6-3/8

7-13/16 6-7/16 7-3/4

7-1/8

8-3/4

8-11/16 9-1/2

9-1/2

9-15/16 10-1/4

5-11/16 7-11/16 9-1/8

6-1/16 7

5-13/16 7-1/2

6-15/16 8-1/2

8-6/16 9-3/16 9-1/8

9-9/16 9-13/16

D 5-3/8

7-3/8

8-3/4

5-5/8

6-3/4

5-1/2

7-3/16 6-11/16 8-1/4

8-1/16 8-7/8

8-13/16 9-1/4

9-7/16

—

7-1/8

—

5-5/16 6-7/16 5-1/8

6-7/8

6-3/8

7-7/8

7-11/16 8-9/16 8-3/16 8-3/4

9-1/16

—

4-11/16 6-1/8

4-13/16 6-3/16 6-1/16 7-1/2

7-1/2

8-1/4

7-15/16 —

—

G —

—

4-3/8

—

4-7/16 —

5-5/8

7-1/8

—

7-11/16 —

—

H —

—

4-3/16 —

4-1/4

—

6-11/16 6-7/8

—

3-7/8

—

6-1/2

—

5-1/2

—

Eighth character: Branch size / discharge valve type
A = 1.5 in. Chk

D = 3 in. Chk

G = 1.5 in. Chk

K = 3 in. PRV

B = 2 in. Chk

E = 4 in. Chk

H = 2 in. PRV

L = 4 in. PRV

C = 2.5 in. Chk

F = 6 in. Chk

J = 2.5 in. PRV

M = 6 in. PRV
