9

2-3 Main Screen Description

The main screen is comprised of six menus and two toolbar buttons located permanently along the

top of the screen. These menus may be used to access the various features of the software. The

toolbar buttons may be used to set Partial Analysis and Blood Pressure Mode parameters.

Toolbar Buttons: (Only for TM-2420/TM-2421, TM-2430)

Button

See

Description

Analysis Intervals

2-4-1 Analysis Intervals

The Analysis Intervals button may be used
to define specific “Full” and “Partial” time
intervals within an opened data file for
custom data analysis.

Note: Not available with the UA-767PC.

BP Mode

2-4-2 BP Mode

The BP Mode selection box may be used
to specify which blood pressure
measurement method (Korotkoff,
oscillometric or both) is used as the basis
for statistical and graphical analysis.

Note: This only applies to TM-2421 data

files.

Main Menus:

Menu

See

Description

File

2-5 File Menu

The File menu may be used to manage the
files stored on the hard drive or a floppy disk
and to exit the software.

View

2-6 View Menu

The View menu may be used to access the
statistical, tabular, and graphical analysis
screens.

Recorder

2-7 Recorder Menu

The Recorder menu may be used to
program the monitor, clear measurement
data in the monitor’s memory and to retrieve
the measurement data from the monitor.

Report

2-8 Report Menu

The Report menu may be used to specify
report formats and print reports.

Option

2-9 Options Menu

The Options menu may be used to set the
default settings and user-defined
parameters.

Help

2-10 On-line Help

The Help menu may be used to view
information on software usage. Help may
also be accessed by pressing F1 when
various screens are opened or by clicking
the Help button on a screen.
