Drawer assembly instructions – Martin Universal Design U-DS92STB Ashley Table with Stool User Manual
Page 8

TOP - 1 PIECE
INSIDE SECTION - 1 PIECE
DRAWERS - 3 PIECES
BOTTOM - 1 PIECE
A
A
B
B
C
C
D
After proper assembly the drawers should
look like the above illustration.
WARNING:
Read all instructions first before assembling drawers. Once pieces are snapped together they are secured.
Drawer Assembly Instructions
Assemble your drawers by taking the section [A] and
snapping into place - by lining up the tabs with the grooves
in the outside edge of section piece [B].
Complete by snapping section [C] onto section A&B.
Finish by sliding the [3] Drawers into the
drawer bank assembly.
D
IMPORTANT:
If you have difficulty assembling your U-DS92ST Creative Center or need customer service assistance. Please call: Martin Universal
Design, Inc. Customer Service Hot Line at 1-313-895-0700. If you need additional parts, it is not necessary to contact your dealer, our
Customer Service Rep. will forward them to you immediately.
